Harness for engine compartment for vehicles with liquid gas operation (lpg) CHGA Volkswagen Golf Plus 2012-2014 EUR

Category content

1. Spare parts table
2. An illustrated scheme of this category is below the list of spare parts

№	Part number	Part name	Наличие	Go to the spare parts page
1	03F972619F	Wiring set for engine	999	Next
1	03F972619G	Wiring set for engine	999	Next
1	03F972619J	Wiring set for engine for vehicles with start-stop	999	Next
1	03F972619H	Wiring set for engine for vehicles with start-stop	999	Next
3	3C0906379	Flat contact housing with contact locking mechanism control unit	999	Next
4	1J0971798C	Sealing tape 220X60X4	999	Next
5	03F971824	Cable guide injection valve	999	Next
7	4D0971993	Flat connector housing with contact locking mechanism high-pressure sensor	999	Next
8	4H0973702A	Flat contact housing high pressure pump	999	Next
9	1J0973081	Flat contact housing with contact locking mechanism oil pressure sender	999	Next
10	8K0973702	Flat contact housing with contact locking mechanism temperature sensor knock sensor additional coolant pump	999	Next
11	07P973702	Flat contact housing with contact locking mechanism injection valve	999	Next
12	8K0973703	Flat contact housing with contact locking mechanism impulse sender camshaft	999	Next
13	8K0973703F	Flat contact housing with contact locking mechanism impulse sender crankshaft for vehicles without start-stop operation	999	Next
13	8K0973703C	Flat contact housing with contact locking mechanism impulse sender crankshaft for vehicles with start-stop	999	Next
15	8K0973704	Flat contact housing with contact locking mechanism pressure sensor intake manifold	999	Next
16	4H0973713F	Flat contact housing with contact locking mechanism servomotor exhaust gas turbocharger	999	Next
17	4H0973713	Flat contact housing with contact locking mechanism throttle valve	999	Next
18	1J0973722	Flat contact housing with contact locking mechanism valve activated carbon filter system solenoid valve	999	Next
19	1J0973724	Flat contact housing ignition coil	999	Next
21	1J0973837	Flat contact housing with contact locking mechanism coupling element central wiring set	999	Next
25	03L971461B	Heat insulation 157X80MM	999	Next
26	1H0971615AB	Cable holder	999	Next
26A	1K0971615DD	Cable guide	999	Next
27	1K0971842F	Bracket wiring set for servotronic	999	Next
28	1K0971858AT	Retaining plate gearbox	999	Next
29	1K0971858BE	Retaining bar gearbox	999	Next
30	1K0971858L	Bracket	999	Next
31	N01508210	Hexagon collar nut M6	999	Next
32	N10744601	Hexagon collar nut self-locking M8	999	Next
33	N90667402	Hexagon bolt M6X10	999	Next
34	1K0972825M	Guide tube	999	Next

Scheme Harness for engine compartment for vehicles with liquid gas operation (lpg) CHGA Volkswagen Golf Plus 2012-2014 EUR
